CABLE ASSEMBLY
PDR provides the broadest choice of patchcords to the industry. All PDR patchcords are tested utilising the industry’s latest equipment and offer superior quality at low prices on all styles of patchcords. 100% Guaranteed!Built to your specifications Simplex/Duplex patchcords with FC, DIN, LC, MU, MTRJ, SC, ST, MPO, D4, Biconic, SMA, E-2000 Connectors are available for either Multimode or Singlemode systems. Upon request, PDR will colour code duplex patchcords for easier identification. PDR patchcord represents high quality, very low loss and maximum performance. A test data sheet can be included with every order upon customer request.Note : PDR patchcords are supplied with orange jacketed multimode (50/125um or 62.5/125um) fiber or yellow jacketed singlemode fiber
MODE CONDITIONING PATCH CORD
Mode Conditioning Patchcord (MCP), also known as Gigabit Launch Patchcord, is used in longwave/long haul (LX/LH) Gigabit Interface Converter (GBICs) with multimode fiber. Without using MCP, multiple signals are generated when a singlemode laser is launched into the center of a multimode fiber. This would result in pulse broadening or Differential Mode Delay (DMD) effects which degrade the modal bandwidth of fiber cable and limit the link span (the distance between the transmitter and receiver) for operating Gigabit Applications. MCP provides an offset singlemode to multimode fiber connector point that eliminates the effect of DMD by launching the singlemode laser into multimode core at a specified offset.
DROP CABLE ASSEMBLY
Drop cable assemblies from PDR are used to transport coupler cable from splice boxes to fiber optic processing equipment. Perfect for use with aerial splice boxes this drop cable can be pre- terminated with any type of fiber optic connector. Suitable for use with cable from 2 to 12 fibers. This connector fits standard CATV receiver boxes.
DROP CABLE ASSEMBLY
Drop cable assemblies from PDR are used to transport coupler cable from splice boxes to fiber optic processing equipment. Perfect for use with aerial splice boxes this drop cable can be pre- terminated with any type of fiber optic connector. Suitable for use with cable from 2 to 12 fibers. This connector fits standard CATV receiver boxes.
PASSIVE COMPONENTS
CONNECTOR
PDR manufactures high quality connectors designed to meet the demands for rapid, accurate and permanent field termination in a variety of environments.
FC CONNECTOR
The non-optical disconnect FC connector is designed with a threaded coupling for durable connections. The ferrule is PC finished to a preradius to ensure low back reflection characteristics. The FC connector is available in a variety of styles including multimode and singlemode.
SC CONNECTOR
The SC is a non-optical disconnect connector with pre-radiused Zirconia ferrule. This connector features a push-pull connection design for quick patching of cables into rack or wall mounts.
LC CONNECTORLC
 is the next generation small form factor (SFF) connector and is ideal for high density applications. LC connector is used on 2mm as well as 3mm cable.
MU CONNECTORMU
 is another type of next generation connector that use 1.2mm ferrule. This small single fiber connector has high level of performance, providing more than double the packaging density of SC connector
ST CONNECTOR
The ST style connector utilises a bayonet twist-lock connection. Available in singlemode and multimode, the ST style connector is noted for reliable and durable field installation
MTRJ CONNECTOR
The MTRJ duplex connector provides increased port density two times that a duplex SC. MTRJ is designed for backbone and horizontal cable systems, local area networks and telecommunication systems
DIN CONNECTOR
PDR DIN connector features a single unit body with spring loaded free-floating zirconia ceramic ferrule. The PDR DIN connectors are available in either single mode or Multimode style. Unique design allows fast polishing of the fiber and enables the installer to achieve low optical loss with high performance physical contact while ensuring maximum repeatability
D4 CONNECTORPDR
non-optical disconnect D4 connector features threaded parts that reduce complexity and assembly time.
SMA 905 AND 906 CONNECTOR
The SMA 905 and 906 multimode connectors are available with stainless steel ferrule
BICONIC CONNECTOR
Biconics provide top performance for multimode and singlemode applications. No other fiber optic connector requires more expertise to manufacture than the Biconic
ATTENUATOR
BULKHEAD (FEMALE TO FEMALE) ATTENUATOR
BULKHEAD ATTENUATOR UTILIZE A WAVELENGTH SENSITIVE NEUTRAL DENSITY FILTERS. SPECIFY FOR 1310NM AND 1550NM OPERATION. AVAILABLE IN SC, ST, FC FOR 5DB, 10DB, 15DB, 20DB, 25DB, 30DB VALUES. OTHER VALUES AVAILABLE ON REQUEST
VARIABLE ATTENUATOR (CLIP-ON TYPE)
Variable attenuator (Clip-On type) is a completely passive device which works by physical attenuation of a 3mm jacketed Singlemode cable. It can be attached at any point in a cable providing attenuation levels from 0 to >47dB at 1550nm, 0 to >21dB at 1310nm and low back reflection. Good for several uses
IN-LINE FIXED ATTENUATOR
The In-Line Fixed Attenuator is built to meet your low reflection attenuation requirements. Each cord is custom built upto 10 meters in length to accommodate your fiber length and connector type. The 5dB and 10dB version hold a +/- 0.5dB tolerance with the 15dB and 20dB holding a 1 dB tolerance. Please specify operating wavelength
VARIABLE ATTENUATOR (AIR-GAP TYPE)
Air-Gap variable attenuator has an alignment sleeve that provides a low insertion loss of 0.15dB and can be used on both multimode and singlemodepplications. Attenuation range is 0dB to 20dB and is available in FC/PC type
PLUG TYPE (MALE TO FEMALE) ATTENUATOR
Plug type attenuator contains doped fiber suitable for dual wavelength operation. Available in FC, SC, ST, LC & MU for 5dB, 10dB, 15dB, 20dB values. Other values available on request
COUPLER
Couplers are available with bare fiber, 900um buffered, 3mm jacketed cable. They are available in premium and standard grades to match your budget and performance requirements. Single window SM Couplers can be ordered to operate in either 1310nm window or 1550nm window. Dual window SM couplers operate in both 1310nm and 1550nm windows. All couplers can be connectorised as per your needs. Available in coupling ratio of 50:50, 70:30, 90:10, 80:20, 60:40 or as per your requirement
ADAPTER
PDR offers a broad range of Adapters like FC, SC, ST, LC, D4, DIN, MU, MTRJ, Biconic and Hybrid Adapters such as FC-LC, SC-LC, FC-SC, FC-ST & SC-ST. All come with a choice of Zirconia Split Sleeve or phosphor bronze sleeve and with a typical insertion loss of 0.1dB
